MC100E150FNG
RoHS
RoHS compliant
RoHS compliantPackage 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Latches
Description
COMPLEMENTARY Surface Mount RoHS Compliant LOW LEVEL D-Type Transparent Latch 900MHz 0C~85C 4.57mm 375ps
PDF
/
Buying Options
Total Price: USD $7.81
Unit Price: USD $7.8128
≥1 USD $7.8128
≥10 USD $6.4106
≥100 USD $6.21015
≥500 USD $6.0097
≥1000 USD $5.8102
Inventory: 1176
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Delay Time - Propagation 375ps
fmax-Min 900 MHz
Independent Circuits 1
Power Supply Current-Max (ICC) 72mA
Trigger Type LOW LEVEL
Prop. Delay@Nom-Sup 0.55 ns
Output Polarity COMPLEMENTARY
Logic Type D-Type Transparent Latch
Output Characteristics OPEN-EMITTER
Number of Bits 6
Supply Voltage-Min (Vsup) 4.2V
Power Supplies -4.5V
Supply Voltage-Max (Vsup) 5.7V
Circuit 6:6
Output Type Differential
Qualification Status Not Qualified
JESD-30 Code S-PQCC-J28
Pin Count 28
Base Part Number 100E150
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code compliant
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.2V~5.7V
Technology ECL
Subcategory FF/Latches
Additional Feature NECL MODE: VCC = 0V WITH VEE = -4.2V TO -5.7V
Terminal Finish Tin (Sn)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 100E
Published 2006
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Surface Mount YES
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
