74F533SC
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount RoHS Compliant Obsolete Lead Free D-Type Transparent Latch 0C 6.7ns 3mA 24mA 5.5V
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
Inventory: 5120
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Supplier Device Package 20-SOIC
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74F
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Voltage - Supply 4.5V~5.5V
Base Part Number 74F533
Output Type Tri-State
Operating Supply Voltage 5V
Number of Elements 1
Circuit 8:8
Polarity Inverting
Number of Circuits 8
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Nominal Supply Current 61mA
Number of Bits 8
Propagation Delay 9 ns
Turn On Delay Time 6.7 ns
Logic Function D-Type, Latch
Current - Output High, Low 3mA 24mA
Logic Type D-Type Transparent Latch
High Level Output Current -3mA
Low Level Output Current 3mA
Number of Input Lines 2
Independent Circuits 1
Number of Output Lines 8
Delay Time - Propagation 6.7ns
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
