74ACTQ843SPC
RoHS
/
Package 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Through Hole RoHS Compliant Obsolete Lead Free D-Type Transparent Latch -40C 6.2ns 24mA 24mA 5.5V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
Inventory: 2696
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.300, 7.62mm)
Number of Pins 24
Supplier Device Package 24-PDIP
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series 74ACTQ
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Supply 4.5V~5.5V
Base Part Number 74ACTQ843
Output Type Tri-State
Operating Supply Voltage 5V
Number of Elements 1
Circuit 9:9
Polarity Non-Inverting
Number of Circuits 9
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of Bits 9
Propagation Delay 9.5 ns
Turn On Delay Time 6.2 ns
Logic Function D-Type, Latch
Current - Output High, Low 24mA 24mA
Logic Type D-Type Transparent Latch
High Level Output Current -24mA
Low Level Output Current 24mA
Number of Input Lines 9
Independent Circuits 1
Number of Output Lines 3
Delay Time - Propagation 6.2ns
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
