74ACQ573SCX
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount RoHS Compliant Obsolete Lead Free D-Type Transparent Latch -40C 5.5ns 24mA 24mA 6V
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
Inventory: 1095
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Delay Time - Propagation 5.5ns
Number of Output Lines 3
Independent Circuits 1
Number of Input Lines 2
Low Level Output Current 24mA
High Level Output Current -24mA
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Logic Function D-Type, Latch
Turn On Delay Time 5.5 ns
Propagation Delay 7 ns
Number of Bits 8
Min Supply Voltage 2V
Max Supply Voltage 6V
Number of Circuits 8
Polarity Non-Inverting
Circuit 8:8
Number of Elements 1
Output Type Tri-State
Base Part Number 74ACQ573
Voltage - Supply 2V~6V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74ACQ
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 20-SOIC
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
