SN74LVC08ADG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free AND Gate Surface Mount ROHS3Compliant AND Gate Inverter IC 50pF -40C~125C 3.6V 24mA 24mA
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.1349
≥1 USD $0.1349
≥10 USD $0.1102
≥100 USD $0.10735
≥500 USD $0.10355
≥1000 USD $0.1007
Inventory: 200992
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 129.387224mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Gates
Technology CMOS
Voltage - Supply 1.65V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 1.8V
Base Part Number 74LVC08
Pin Count 14
Number of Outputs 1
Number of Elements 4
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Load Capacitance 50pF
Output Current 24mA
Propagation Delay 3.9 ns
Quiescent Current 1μA
Turn On Delay Time 4.1 ns
Family LVC/LCX/Z
Logic Function AND
Number of Inputs 2
Current - Output High, Low 24mA 24mA
Logic Type AND Gate
Max Propagation Delay @ V, Max CL 3.9ns @ 3.3V, 50pF
Prop. Delay@Nom-Sup 5.5 ns
Schmitt Trigger NO
Logic Level - Low 0.7V ~ 0.8V
Logic Level - High 1.7V ~ 2V
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
