SN74LS30DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NAND e4 SOIC LS logic gate circuit 20ns 129.387224mg 8mA 5.25V
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.3496
≥1 USD $0.3496
≥10 USD $0.2869
≥100 USD $0.2774
≥500 USD $0.26885
≥1000 USD $0.2603
Inventory: 1100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Technical
Number of Input Lines 8
Schmitt Trigger NO
Low Level Output Current 400μA
High Level Output Current -16mA
Logic Function NAND
Family LS
Turn On Delay Time 22 ns
Propagation Delay 20 ns
Current - Output 8mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Number of Circuits 1
Temperature Grade COMMERCIAL
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 14
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Packing Method TUBE
Subcategory Gates
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case SOIC
Mount Surface Mount
Alternative Model
