SN74LS04NS
RoHS
/
Package 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
74LS04 EAR99 74LS Tube logic gate circuit 15ns @ 5V 15pF 2mm 400muA 8mA 5.25V
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.71544
≥100 USD $0.67936
≥500 USD $0.558096
≥1000 USD $0.521664
≥3000 USD $0.461014
Inventory: 1083
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74LS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Gates
Packing Method TR
Technology TTL
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 6
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74LS04
Pin Count 14
JESD-30 Code R-PDSO-G14
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Number of Circuits 6
Load Capacitance 15pF
Family LS
Number of Inputs 1
Current - Output High, Low 400μA 8mA
Logic Type Inverter
Max I(ol) 0.008 A
Max Propagation Delay @ V, Max CL 15ns @ 5V, 15pF
Prop. Delay@Nom-Sup 15 ns
Propagation Delay (tpd) 15 ns
Schmitt Trigger NO
Logic Level - Low 0.4V ~ 0.5V
Logic Level - High 3.4V
Dimensions
Height Seated (Max) 2mm
Length 10.2mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
