SN74HC02PWT
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NOR 74HC02 EAR99 74HC logic gate circuit 15ns @ 6V 50pF 1.2mm 5.2mA 5.2mA 6V
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.968
≥1 USD $0.968
≥10 USD $0.86768
≥100 USD $0.82368
≥500 USD $0.676632
Inventory: 1129
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Logic Level - High 1.5V ~ 4.2V
Logic Level - Low 0.5V ~ 1.8V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 15ns @ 6V, 50pF
Logic Type NOR Gate
Current - Output High, Low 5.2mA 5.2mA
Number of Inputs 2
Logic Function NOR
Family HC/UH
Quiescent Current 2μA
Propagation Delay 15 ns
Output Current 5.2mA
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 4
Operating Supply Voltage 5V
Max Output Current 5.2mA
Number of Outputs 1
Pin Count 14
Base Part Number 74HC02
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Subcategory Gates
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 57.209338mg
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
