SN74AS86ADR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
XOR (Exclusive OR) Surface Mount ROHS3Compliant Not Qualified XOR (Exclusive OR) Inverter IC 50pF 0C~70C 5.5V 2mA 20mA
PDF
/
Inventory: 1470
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Power Supply Current-Max (ICC) 38mA
Logic Level - High 2V
Logic Level - Low 0.8V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 7.5ns @ 5V, 50pF
Logic Type XOR (Exclusive OR)
Current - Output High, Low 2mA 20mA
Number of Inputs 2
Logic Function OR, XOR
Family AS
Turn On Delay Time 7.5 ns
Propagation Delay 7.5 ns
Load Capacitance 50pF
Number of Circuits 4
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Pin Count 14
Base Part Number 74AS86
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Packing Method TAPE AND REEL
Subcategory Gates
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74AS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
