SN74AS04D
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
74AS04 EAR99 74AS Tube logic gate circuit 5ns @ 5V 50pF 1.75mm 2mA 20mA 2V
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.27424
≥100 USD $1.209472
≥500 USD $0.99352
≥1000 USD $0.928717
≥3000 USD $0.820723
Inventory: 1628
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Schmitt Trigger Input No
Logic Level - High 2V
Logic Level - Low 0.8V
Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
Max I(ol) 0.02 A
Logic Type Inverter
Current - Output High, Low 2mA 20mA
Output Characteristics 3-STATE
Family AS
Turn On Delay Time 5 ns
Propagation Delay 5 ns
Output Current 20mA
Load Capacitance 50pF
Power Supplies 5V
Number of Elements 6
Operating Supply Voltage 5V
Pin Count 14
Base Part Number 74AS04
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 6
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory Gates
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74AS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
