SN74ALVC08DR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
AND 74ALVC08 EAR99 74ALVC logic gate circuit 2.9ns @ 3.3V 50pF 1.75mm 24mA 24mA 3.6V
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.36872
≥100 USD $0.336864
≥500 USD $0.2508
≥1000 USD $0.227251
≥3000 USD $0.188074
Inventory: 11320
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 129.387224mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74ALVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Subcategory Gates
Packing Method TR
Technology CMOS
Voltage - Supply 1.65V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 1.8V
Base Part Number 74ALVC08
Pin Count 14
Number of Outputs 1
Number of Elements 4
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Load Capacitance 50pF
Output Current 24mA
Propagation Delay 2.9 ns
Quiescent Current 10μA
Turn On Delay Time 2.9 ns
Family ALVC/VCX/A
Logic Function AND
Number of Inputs 2
Current - Output High, Low 24mA 24mA
Logic Type AND Gate
Max Propagation Delay @ V, Max CL 2.9ns @ 3.3V, 50pF
Schmitt Trigger NO
Logic Level - Low 0.7V ~ 0.8V
Logic Level - High 1.7V ~ 2V
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
