SN74ALS20ADBR
RoHS
RoHS compliant
RoHS compliantPackage 14-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free NAND Gate Surface Mount ROHS3Compliant NAND Gate Inverter IC 0C~70C 5.5V 400muA 8mA 0.65mm
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.448339
≥1 USD $0.448339
≥10 USD $0.422961
≥100 USD $0.39902
≥500 USD $0.376428
≥1000 USD $0.355124
Inventory: 1110
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Technical
Power Supply Current-Max (ICC) 1.5mA
Logic Level - High 2V
Logic Level - Low 0.8V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 12.5ns @ 5V, 50pF
Max I(ol) 0.008 A
Logic Type NAND Gate
Current - Output High, Low 400μA 8mA
Number of Inputs 4
Logic Function NAND
Family ALS
Turn On Delay Time 11 ns
Propagation Delay 12.5 ns
Output Current 8mA
Number of Circuits 2
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 14
Base Part Number 74ALS20
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Packing Method TAPE AND REEL
Subcategory Gates
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74ALS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
