CD4075BMT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Contains Lead OR Gate SMD/SMT Surface Mount OR Gate Inverter IC 50pF -55C~125C 3.5V-11V 3.4mA 3.4mA
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.401443
≥1 USD $0.401443
≥10 USD $0.378726
≥100 USD $0.357286
≥500 USD $0.337062
≥1000 USD $0.317981
Inventory: 1268
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Termination SMD/SMT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 3
Supply Voltage 5V
Base Part Number CD4075
Pin Count 14
Number of Outputs 1
Max Output Current 6.8mA
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Output Current 6.8mA
Propagation Delay 90 ns
Quiescent Current 1μA
Turn On Delay Time 250 ns
Logic Function OR
Current - Output High, Low 3.4mA 3.4mA
Logic Type OR Gate
Number of Gates 3
Max Propagation Delay @ V, Max CL 90ns @ 15V, 50pF
Schmitt Trigger NO
Logic Level - Low 1.5V ~ 4V
Logic Level - High 3.5V ~ 11V
Dimensions
Length 8.65mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
