CD4002BMG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free NOR Gate Surface Mount ROHS3Compliant NOR Gate Inverter IC 50pF -55C~125C 3.5V-11V 3.4mA 3.4mA
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.811313
≥1 USD $1.811313
≥10 USD $1.708795
≥100 USD $1.612067
≥500 USD $1.520817
≥1000 USD $1.434734
Inventory: 1184
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 129.387224mg
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Subcategory Gates
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Base Part Number CD4002
Pin Count 14
Number of Outputs 1
Number of Elements 2
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Output Current 6.8mA
Propagation Delay 90 ns
Quiescent Current 5μA
Turn On Delay Time 90 ns
Logic Function NOR
Number of Inputs 4
Current - Output High, Low 3.4mA 3.4mA
Logic Type NOR Gate
Max I(ol) 0.0068 A
Max Propagation Delay @ V, Max CL 90ns @ 15V, 50pF
Logic Level - Low 1.5V ~ 4V
Logic Level - High 3.5V ~ 11V
Power Supply Current-Max (ICC) 0.03mA
Current - Quiescent (Max) 1μA
Schmitt Trigger Input No
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
