M74HCT02RM13TR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NOR M74HCT02 e4 74HCT logic gate circuit 24ns @ 4.5V 50pF 8.65mm 4mA 4mA 2V
PDF
/
Inventory: 1602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Technical
Logic Level - High 2V
Logic Level - Low 0.8V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 24ns @ 4.5V, 50pF
Number of Gates 4
Logic Type NOR Gate
Current - Output High, Low 4mA 4mA
Number of Inputs 2
Logic Function NOR
Family HCT
Turn On Delay Time 36 ns
Quiescent Current 1μA
Propagation Delay 24 ns
Load Capacitance 50pF
Voltage 5V
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number M74HCT02
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Gates
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74HCT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
