74VHCT02AMTR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NOR 74VHCT02 74VHCT Tape & Reel (TR) logic gate circuit 8ns @ 5V 50pF 8mA 8mA 2V 125C
PDF
/
Inventory: 3322
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Current - Quiescent (Max) 2μA
Logic Level - High 2V
Logic Level - Low 0.8V
Low Level Output Current 8mA
High Level Output Current -8mA
Max Propagation Delay @ V, Max CL 8ns @ 5V, 50pF
Number of Gates 4
Logic Type NOR Gate
Current - Output High, Low 8mA 8mA
Number of Inputs 2
Logic Function NOR
Turn On Delay Time 8 ns
Quiescent Current 2μA
Propagation Delay 8 ns
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Circuits 4
Number of Elements 4
Operating Supply Voltage 5V
Number of Outputs 1
Base Part Number 74VHCT02
Voltage - Supply 4.5V~5.5V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74VHCT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Supplier Device Package 14-SO
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
