74V2GU04STR
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-8
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
74V2GU04 74V Tape & Reel (TR) AHC/VHC/H/U/V logic gate circuit 6ns @ 5V 50pF 1.45mm 8mA 8mA 5.5V
PDF
/
Inventory: 920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.625mm
Length 2.9mm
Height Seated (Max) 1.45mm
Technical
Logic Level - High 1.7V
Logic Level - Low 0.3V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 6ns @ 5V, 50pF
Number of Gates 3
Max I(ol) 0.004 A
Logic Type Inverter
Current - Output High, Low 8mA 8mA
Family AHC/VHC/H/U/V
Turn On Delay Time 10 ns
Quiescent Current 1μA
Propagation Delay 6 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/5.5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 74V2GU04
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Gates
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74V
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 8
Package / Case SOT-23-8
Mounting Type Surface Mount
Mount Surface Mount
