74V1G08STR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
AND 74V1G08 e3 74V logic gate circuit 7ns @ 5V 50pF 900mum 8mA 8mA 1.5V
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 7803
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.75mm
Length 3mm
Height 900μm
Technical
Logic Level - High 1.5V
Logic Level - Low 0.5V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 7ns @ 5V, 50pF
Number of Gates 1
Max I(ol) 0.004 A
Logic Type AND Gate
Current - Output High, Low 8mA 8mA
Number of Inputs 2
Logic Function AND
Family 74V
Turn On Delay Time 8.5 ns
Quiescent Current 1μA
Propagation Delay 9 ns
Output Current 8mA
Supply Voltage-Min (Vsup) 2V
Max Output Current 8mA
Pin Count 5
Base Part Number 74V1G08
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Subcategory Gates
Terminal Finish Matte Tin (Sn) - annealed
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 74V
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 4.535924g
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
