74LVC14AMTR
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Buffer Inverter Schmitt Trigger 74LVC14 8542.39.00.01 74LVC logic gate circuit 6.4ns @ 3.3V 50pF 1.75mm 24mA 24mA 1.4V-2.2V
PDF
/
Inventory: 4557
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 1.65V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 6
Supply Voltage 2.7V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 74LVC14
Pin Count 14
Power Supplies 3.3V
Load Capacitance 50pF
Propagation Delay 6.4 ns
Quiescent Current 10μA
Turn On Delay Time 14 ns
Family LVC/LCX/Z
Logic Function Buffer, Inverter, Schmitt Trigger
Current - Output High, Low 24mA 24mA
Logic Type Inverter
Number of Gates 6
Max Propagation Delay @ V, Max CL 6.4ns @ 3.3V, 50pF
Prop. Delay@Nom-Sup 5 ns
Schmitt Trigger YES
Logic Level - Low 0.3V ~ 0.8V
Logic Level - High 1.4V ~ 2.2V
Dimensions
Height Seated (Max) 1.75mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
