CD74HCT08E
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
AND Gate Through Hole Non-RoHS Compliant Not Qualified AND Gate Inverter IC -55C~125C 5.5V 4mA 4mA 25ns @ 4.5V 50pF
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 24566
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 74HCT
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Number of Functions 4
Supply Voltage 5V
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Number of Circuits 4
Family HCT
Number of Inputs 2
Current - Output High, Low 4mA 4mA
Logic Type AND Gate
Max Propagation Delay @ V, Max CL 25ns @ 4.5V, 50pF
Propagation Delay (tpd) 38 ns
Logic Level - Low 0.8V
Logic Level - High 2V
Current - Quiescent (Max) 2μA
Compliance
RoHS Status Non-RoHS Compliant
