CD74ACT05E
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Inverter Through Hole Non-RoHS Compliant Obsolete Inverter Inverter IC -55C~125C 5.5V - 24mA 10.8ns @ 5V 50pF
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.836
≥1 USD $0.836
≥10 USD $0.74448
≥100 USD $0.706816
≥500 USD $0.580536
≥1000 USD $0.542714
≥3000 USD $0.4796
Inventory: 365
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 74ACT
Feature Open Drain
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Number of Functions 6
Supply Voltage 5V
Pin Count 14
JESD-30 Code R-PDIP-T14
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Number of Circuits 6
Family ACT
Number of Inputs 1
Current - Output High, Low - 24mA
Logic Type Inverter
Max Propagation Delay @ V, Max CL 10.8ns @ 5V, 50pF
Propagation Delay (tpd) 9.3 ns
Logic Level - Low 0.8V
Logic Level - High 2V
Current - Quiescent (Max) 4μA
Compliance
RoHS Status Non-RoHS Compliant
