CD4069UBCSJ
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Inverter Surface Mount ROHS3Compliant COMMERCIAL Inverter Inverter IC -55C~125C 15V 3.4mA 3.4mA 2.1mm
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 6005
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 10.2mm
Height Seated (Max) 2.1mm
Technical
Current - Quiescent (Max) 1μA
Logic Level - High 4V ~ 12V
Logic Level - Low 1V ~ 3V
Propagation Delay (tpd) 90 ns
Max Propagation Delay @ V, Max CL 50ns @ 15V, 50pF
Logic Type Inverter
Current - Output High, Low 3.4mA 3.4mA
Number of Inputs 1
Family 4000/14000/40000
Number of Circuits 6
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 15V
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G14
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 6
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~15V
Technology CMOS
Terminal Finish MATTE TIN
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount YES
Package / Case 14-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
