74LVQ32SC
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
OR Gate Surface Mount ROHS3Compliant COMMERCIAL OR Gate Inverter IC -40C~85C 3.6V 12mA 12mA 1.75mm
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.1848
≥1 USD $0.1848
Inventory: 2417
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Current - Quiescent (Max) 2μA
Logic Level - High 2V
Logic Level - Low 0.8V
Max Propagation Delay @ V, Max CL 9ns @ 3.3V, 50pF
Logic Type OR Gate
Current - Output High, Low 12mA 12mA
Number of Inputs 2
Family LVQ
Number of Circuits 4
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status COMMERCIAL
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 2.7V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~3.6V
Technology CMOS
Terminal Finish MATTE TIN
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74LVQ
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
