74F02SJ
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
e3 74F Tube F/FAST logic gate circuit 5.5ns @ 5V 50pF 5.3mm 1mA 20mA 5.5V
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 9822
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74F
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish MATTE TIN
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 14
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Number of Circuits 4
Family F/FAST
Number of Inputs 2
Current - Output High, Low 1mA 20mA
Logic Type NOR Gate
Max Propagation Delay @ V, Max CL 5.5ns @ 5V, 50pF
Propagation Delay (tpd) 6.5 ns
Logic Level - Low 0.8V
Logic Level - High 2V
Dimensions
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
