MC74LVX32DR2
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Contains Lead OR Gate Surface Mount Non-RoHS Compliant OR Gate Inverter IC 50pF -40C~85C 3.6V 4mA 4mA
PDF
/
Buying Options
Total Price: USD $2.52
Unit Price: USD $2.52225
≥1 USD $2.52225
≥10 USD $2.07005
≥100 USD $2.00545
≥500 USD $1.9399
≥1000 USD $1.8753
Inventory: 1200
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2009
Series 74LVX
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 2.7V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74LVX32
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Propagation Delay 10.1 ns
Quiescent Current 2μA
Turn On Delay Time 14.2 ns
Family LV/LV-A/LVX/H
Logic Function OR
Number of Inputs 2
Current - Output High, Low 4mA 4mA
Logic Type OR Gate
Number of Gates 4
Max Propagation Delay @ V, Max CL 10.1ns @ 3.3V, 50pF
Schmitt Trigger NO
Logic Level - Low 0.5V ~ 0.8V
Logic Level - High 1.5V ~ 2.4V
Dimensions
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
