MC74LCXU04DR2
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Contains Lead Inverter Surface Mount Non-RoHS Compliant Inverter Inverter IC 50pF -40C~85C 1.7V-2.7V 18mA 16mA
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.20834
≥1 USD $0.20834
≥10 USD $0.196546
≥100 USD $0.185419
≥500 USD $0.174921
≥1000 USD $0.165024
Inventory: 1126
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2009
Series 74LCX
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.39.00.01
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 6
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74LCXU04
Pin Count 14
Qualification Status Not Qualified
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 2V
Number of Circuits 6
Load Capacitance 50pF
Propagation Delay 3.6 ns
Quiescent Current 10μA
Family LVC/LCX/Z
Current - Output High, Low 18mA 16mA
Logic Type Inverter
Max Propagation Delay @ V, Max CL 3.6ns @ 3.3V, 50pF
Schmitt Trigger NO
Logic Level - Low 0.55V
Logic Level - High 1.7V ~ 2.7V
Dimensions
Height Seated (Max) 1.75mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
