MC14093BDTR2G
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NAND Schmitt Trigger 4093 e4 4000B logic gate circuit 80ns @ 15V 50pF 1.05mm 8.8mA 8.8mA 3.6V-10.8V
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.49016
≥100 USD $0.460064
≥500 USD $0.348832
≥1000 USD $0.296877
≥3000 USD $0.282022
Inventory: 1541
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.5mm
Length 5.1mm
Height 1.05mm
Technical
Schmitt Trigger Input Yes
Logic Level - High 3.6V ~ 10.8V
Logic Level - Low 0.9V ~ 4V
Max Propagation Delay @ V, Max CL 80ns @ 15V, 50pF
Logic Type NAND Gate
Current - Output High, Low 8.8mA 8.8mA
Halogen Free Halogen Free
Number of Inputs 2
Logic Function NAND, Schmitt Trigger
Turn On Delay Time 250 ns
Quiescent Current 1μA
Propagation Delay 80 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 4
Output Type TTL
Number of Outputs 1
Pin Count 14
Base Part Number 4093
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Gates
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Schmitt Trigger
JESD-609 Code e4
Series 4000B
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 45 Weeks
