MC14011BCPG
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NAND 4011 e3 4000B logic gate circuit 80ns @ 15V 50pF 3.68mm 8.8mA 8.8mA 3.5V-11V
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 796
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.6mm
Length 19.56mm
Height 3.68mm
Technical
Logic Level - High 3.5V ~ 11V
Logic Level - Low 1.5V ~ 4V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 80ns @ 15V, 50pF
Number of Gates 4
Logic Type NAND Gate
Current - Output High, Low 8.8mA 8.8mA
Number of Inputs 2
Logic Function NAND
Turn On Delay Time 80 ns
Quiescent Current 1μA
Propagation Delay 80 ns
Output Current 8.8mA
Load Capacitance 50pF
Voltage 20V
Number of Outputs 1
Pin Count 14
Base Part Number 4011
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method RAIL
Subcategory Gates
Terminal Finish Tin (Sn)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 4000B
Published 2006
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 4.535924g
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
