DM74ALS09MX
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
AND 74ALS09 74ALS Tape & Reel (TR) logic gate circuit 54ns @ 5V 50pF - 8mA 2V 70C
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
Inventory: 1115
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Supplier Device Package 14-SOIC
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74ALS
Feature Open Collector
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Voltage - Supply 4.5V~5.5V
Base Part Number 74ALS09
Number of Outputs 1
Operating Supply Voltage 5V
Number of Elements 4
Number of Circuits 4
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Propagation Delay 54 ns
Turn On Delay Time 54 ns
Logic Function AND
Number of Inputs 2
Current - Output High, Low - 8mA
Logic Type AND Gate
Number of Gates 4
Max Propagation Delay @ V, Max CL 54ns @ 5V, 50pF
High Level Output Current -100μA
Low Level Output Current 8mA
Logic Level - Low 0.8V
Logic Level - High 2V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
