74AC08PC
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free AND Gate Through Hole RoHS Compliant AND Gate Inverter IC -40C~85C 6V 24mA 24mA 1.62g
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
Inventory: 1097
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Logic Level - High 2.1V ~ 3.85V
Logic Level - Low 0.9V ~ 1.65V
Max Propagation Delay @ V, Max CL 7.5ns @ 5V, 50pF
Number of Gates 4
Logic Type AND Gate
Current - Output High, Low 24mA 24mA
Number of Inputs 2
Logic Function AND
Family AC
Turn On Delay Time 9.5 ns
Quiescent Current 2μA
Propagation Delay 10 ns
Output Current 24mA
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Outputs 1
Base Part Number 74AC08
Supply Voltage 3.3V
Number of Functions 4
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74AC
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.62g
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
