74AC04PC
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free Inverter Through Hole RoHS Compliant Inverter Inverter IC -40C~85C 2.1V-3.85V 24mA 24mA 1.62g
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
Inventory: 1280
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Logic Level - High 2.1V ~ 3.85V
Logic Level - Low 0.9V ~ 1.65V
Max Propagation Delay @ V, Max CL 7ns @ 5V, 50pF
Number of Gates 6
Logic Type Inverter
Current - Output High, Low 24mA 24mA
Logic Function Buffer, Inverter
Turn On Delay Time 10 ns
Quiescent Current 2μA
Propagation Delay 10 ns
Output Current 24mA
Base Part Number 74AC04
Voltage - Supply 2V~6V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74AC
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.62g
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
