CD4085BPWE4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description 4000B AND/OR/INVERT Gate Tube CD4085 multi inverter 5mm 620ns 5/15V 6.8mA 6.8mA
PDF
/
Inventory: 8442
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14

Technical

Operating Temperature -55°C~125°C
Packaging Tube
Series 4000B
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Subcategory Gates
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number CD4085
Pin Count 14
Output Type Single-Ended
Supply Voltage-Max (Vsup) 18V
Power Supplies 5/15V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 2
Load Capacitance 50pF
Output Current 6.8mA
Propagation Delay 620 ns
Logic Function AND, OR
Number of Inputs 8 Input (2, 2, 2, 2)
Current - Output High, Low 6.8mA 6.8mA
Logic Type AND/OR/INVERT Gate
Schmitt Trigger Input No

Dimensions

Length 5mm
Width 4.4mm

Compliance

RoHS Status ROHS3 Compliant
