CD4019BM
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
ACTIVE (Last Updated: 3days ago) 4000B AND/OR Gate Tube multi inverter 141.690917mg 100ns 5V 6.8mA 6.8mA
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.9152
≥100 USD $0.86856
≥500 USD $0.71346
≥1000 USD $0.666917
Inventory: 529
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Schmitt Trigger Input No
Prop. Delay@Nom-Sup 300 ns
Max I(ol) 0.0068 A
Logic Type AND/OR Gate
Current - Output High, Low 6.8mA 6.8mA
Number of Inputs 2
Logic Function AND, OR
Turn On Delay Time 100 ns
Quiescent Current 40nA
Propagation Delay 120 ns
Output Current 6.8mA
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 4
Output Type Single-Ended
Number of Outputs 1
Pin Count 16
Base Part Number CD4019
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Subcategory Gates
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
