CD4019BE
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
ACTIVE (Last Updated: 1day ago) 4000B AND/OR Gate Tube multi inverter 951.693491mg 100ns 5V 6.8mA 6.8mA
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.50512
≥100 USD $0.474496
≥500 USD $0.387288
≥1000 USD $0.359744
≥3000 USD $0.306152
Inventory: 1505
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Schmitt Trigger Input No
Input Capacitance 5pF
Prop. Delay@Nom-Sup 300 ns
Max I(ol) 0.0068 A
Logic Type AND/OR Gate
Current - Output High, Low 6.8mA 6.8mA
Number of Inputs 2
Logic Function AND, OR
Turn On Delay Time 100 ns
Quiescent Current 20μA
Propagation Delay 120 ns
Output Current 6.8mA
Power Dissipation 500mW
Load Capacitance 50pF
Number of Channels 4
Supply Voltage-Min (Vsup) 3V
Max Output Current 6.8mA
Output Type Single-Ended
Number of Outputs 1
Pin Count 16
Base Part Number CD4019
Supply Voltage 5V
Number of Functions 4
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Subcategory Gates
ECCN Code EAR99
Termination Through Hole
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 951.693491mg
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
