MC10H101MELG
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Surface Mount Obsolete ROHS3Compliant DUAL NOR/OR Gate Inverter IC 0C~75C 1.6ns 10.2mm
PDF
/
Buying Options
Total Price: USD $2.79
Unit Price: USD $2.7949
≥1 USD $2.7949
≥10 USD $2.2933
≥100 USD $2.22205
≥500 USD $2.14985
≥1000 USD $2.0786
Inventory: 3015
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.275mm
Length 10.2mm
Height Seated (Max) 2.05mm
Technical
Schmitt Trigger Input No
Propagation Delay (tpd) 1.6 ns
Logic Type NOR/OR Gate
Number of Inputs 8 Input (2, 2, 2, 2)
Family 10H
Number of Circuits 4
Output Type Differential
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology ECL
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Series 10H
Packaging Tape & Reel (TR)
Operating Temperature 0°C~75°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
