MC10E107FNG
RoHS
RoHS compliant
RoHS compliantPackage 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Surface Mount Obsolete ROHS3Compliant QUAD XOR/XNOR Gate Inverter IC -40C~85C 5V 0.6ns 1.27mm
PDF
/
Buying Options
Total Price: USD $5.66
Unit Price: USD $5.6584
≥1 USD $5.6584
Inventory: 13490
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Schmitt Trigger Input No
Propagation Delay (tpd) 0.6 ns
Logic Type XOR/XNOR Gate
Output Characteristics OPEN-EMITTER
Number of Inputs 10 Input (2, 2, 2, 2, 2)
Family 10E
Number of Circuits 5
Supply Voltage-Min (Vsup) 4.2V
Output Type Differential
Qualification Status COMMERCIAL
JESD-30 Code S-PQCC-J28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 5
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.2V~5.7V
Technology ECL
Terminal Finish MATTE TIN
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Series 10E
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
