MC100LVEL12D image
Favorite
MC100LVEL12D image
Favorite
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description OPEN-EMITTER TIN LEAD NECL MODE: VCC = 0V WITH VEE = -3.0V TO -3.8V 100LVEL multi inverter 4.9mm 0.58ns 3.3V -40C~85C
PDF
/
Buying Options
Total Price: USD $8.33
Unit Price: USD $8.33245
≥1 USD $8.33245
≥10 USD $6.83715
≥100 USD $6.6234
≥500 USD $6.40965
≥1000 USD $6.1959
Inventory: 1410
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 3.9mm
Length 4.9mm

Technical

Schmitt Trigger Input No
Propagation Delay (tpd) 0.58 ns
Logic Type NOR/OR Gate
Output Characteristics OPEN-EMITTER
Number of Inputs 2
Number of Circuits 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.8V
Output Type Differential
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply -3V~-3.8V
Technology ECL
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3.0V TO -3.8V
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Series 100LVEL
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
