NLX1G57AMX1TCG
RoHS
/
Package 6-XFLGA
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Nickel/Palladium/Gold (Ni/Pd/Au) 1G MiniGate? Configurable Multiple Function multi inverter 0.4mm 5.1ns 2.3V 32mA 32mA
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.117223
≥1 USD $0.117223
≥10 USD $0.110591
≥100 USD $0.104331
≥500 USD $0.098423
≥1000 USD $0.092856
Inventory: 1257
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-XFLGA
Number of Pins 6
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series MiniGate?
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 2.3V
Terminal Pitch 0.5mm
Base Part Number NLX1G57
Pin Count 6
Output Type Single-Ended
Supply Voltage-Max (Vsup) 5.5V
Propagation Delay 5.1 ns
Quiescent Current 1μA
Family 1G
Logic Function Multi Function
Number of Inputs 3
Current - Output High, Low 32mA 32mA
Logic Type Configurable Multiple Function
Max I(ol) 0.008 A
Number of Gates 1
Number of Input Lines 2
Schmitt Trigger Input No
Dimensions
Height Seated (Max) 0.4mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
