NC7SZ58FHX
RoHS
RoHS compliant
RoHS compliantPackage 6-UFDFN
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Nickel/Palladium (Ni/Pd) LVC/LCX/Z ACTIVE (Last Updated: 4days ago) 7SZ multiple gates 20mg 6.5ns 2.3V 32mA 32mA
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.0792
≥1 USD $0.0792
Inventory: 222121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-UFDFN
Number of Pins 2
Weight 20mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2017
Series 7SZ
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium (Ni/Pd)
Subcategory Gates
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.3V
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number 7SZ58
JESD-30 Code S-PDSO-N6
Output Type Single-Ended
Supply Voltage-Max (Vsup) 5.5V
Load Capacitance 50pF
Propagation Delay 3.5 ns
Quiescent Current 1μA
Family LVC/LCX/Z
Logic Function Multi Function
Number of Inputs 3
Current - Output High, Low 32mA 32mA
Logic Type Configurable Multiple Function
Number of Gates 1
Prop. Delay@Nom-Sup 6.5 ns
Schmitt Trigger Input No
Dimensions
Height Seated (Max) 0.55mm
Compliance
RoHS Status ROHS3 Compliant
