MC10H121M
RoHS
/
Package 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Nickel/Palladium/Gold (Ni/Pd/Au) 10H 10H AND/OR/INVERT Gate multiple gates 2.05mm 2ns -5.46V -50mA
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.9152
≥1000 USD $1.85155
Inventory: 1135
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209, 5.30mm Width)
Number of Pins 16
Technical
Operating Temperature 0°C~75°C
Packaging Tube
Published 2006
Series 10H
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Gates
Packing Method RAIL
Technology ECL
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Base Part Number 10H121
Pin Count 16
Output Type Single-Ended
Number of Circuits 1
Max Supply Voltage -5.46V
Min Supply Voltage -4.94V
Propagation Delay 2 ns
Family 10H
Logic Function AND, OR
Number of Inputs 4
Logic Type AND/OR/INVERT Gate
High Level Output Current -50mA
Low Level Output Current 50mA
Schmitt Trigger Input No
Dimensions
Height Seated (Max) 2.05mm
Width 5.275mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
