MC10EL01DTR2G

ON Semiconductor
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description Tin (Sn) 10EL NOR/OR Gate Tape & Reel (TR) multi inverter 3mm 0.37ns 5V -50mA
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.8512
≥1 USD $2.8512
Inventory: 1157
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 3mm
Length 3mm

Technical

Schmitt Trigger Input No
Low Level Output Current 50mA
High Level Output Current -50mA
Prop. Delay@Nom-Sup 0.37 ns
Number of Gates 1
Logic Type NOR/OR Gate
Halogen Free Halogen Free
Number of Inputs 4
Logic Function NOR, OR
Quiescent Current 14mA
Propagation Delay 330 ps
Supply Voltage-Max (Vsup) 5.7V
Output Type Differential
Number of Outputs 2
Pin Count 8
Base Part Number 10EL01
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.2V~5.7V
Technology ECL
Packing Method TAPE AND REEL
Subcategory Gates
Terminal Finish Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 10EL
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
