MC100EP08D
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
Surface Mount Obsolete Non-RoHS Compliant Contains Lead XOR/XNOR Gate Inverter IC -40C~85C -50mA -4.5V 0.32ns
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.91315
≥1 USD $6.91315
≥10 USD $5.67245
≥100 USD $5.4948
≥500 USD $5.31715
≥1000 USD $5.14045
Inventory: 1469
Minimum: 1
-
+
Technical Details
Technical
Supply Voltage-Max (Vsup) 5.5V
Power Supplies -4.5V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Propagation Delay 300 ps
Quiescent Current 30mA
Logic Function XNOR, XOR
Number of Inputs 2 Input (1, 1)
Logic Type XOR/XNOR Gate
Prop. Delay@Nom-Sup 0.32 ns
High Level Output Current -50mA
Low Level Output Current 50mA
Power Supply Current-Max (ICC) 40mA
Schmitt Trigger Input No
Output Type Differential
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number 100EP08
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology ECL
Packing Method RAIL
Subcategory Gates
Additional Feature NECL MODE: 0V VCC WITH VEE = -3.0V TO -5.5V
Terminal Finish Tin/Lead (Sn80Pb20)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series 100EP
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
