MC100E101FNR2
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description
OPEN-EMITTER Tin/Lead (Sn/Pb) 100E NOR/OR Gate multiple gates 11.505mm 500ps 5V -50mA
PDF
/
Buying Options
Total Price: USD $400.13
Unit Price: USD $400.134067
≥1 USD $400.134067
≥10 USD $386.976846
≥25 USD $384.286841
≥50 USD $381.61553
≥100 USD $373.766438
≥500 USD $347.044045
Inventory: 1418
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 11.505mm
Length 11.505mm
Technical
Schmitt Trigger Input No
Low Level Output Current 50mA
High Level Output Current -50mA
Prop. Delay@Nom-Sup 0.5 ns
Number of Gates 4
Logic Type NOR/OR Gate
Output Characteristics OPEN-EMITTER
Number of Inputs 16 Input (4, 4, 4, 4)
Logic Function NOR, OR
Turn On Delay Time 500 ps
Quiescent Current 30mA
Propagation Delay 600 ps
Supply Voltage-Max (Vsup) 5.7V
Output Type Differential
Number of Outputs 2
Pin Count 28
Base Part Number 100E101
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 240
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.2V~5.7V
Technology ECL
Packing Method TAPE AND REEL
Subcategory Gates
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Series 100E
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
