SY100S307JZ image
Favorite
SY100S307JZ image
Favorite
RoHS
RoHS RoHS compliant
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters - Multi-Function, Configurable
Description IC GATE XOR/NOR QUINT 28-PLCC
PDF
/
Inventory: 9472
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Schmitt Trigger Input No
Logic Type XOR/NOR Gate
Number of Inputs 10 Input (2, 2, 2, 2, 2)
Logic Function NOR, XNOR, XOR
Min Supply Voltage -4.2V
Max Supply Voltage -5.5V
Number of Circuits 5
Number of Elements 5
Output Type Differential
Base Part Number 100S307
Voltage - Supply 4.2V~5.5V
Min Operating Temperature 0°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Series 100S
Published 2010
Packaging Tube
Operating Temperature 0°C~85°C

Physical

Supplier Device Package 28-PLCC (11.48x11.48)
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
