TC7WT74FUTE12LF image
Favorite
TC7WT74FUTE12LF image
Favorite
RoHS
/
Package 8-TSSOP, 8-MSOP (0.110, 2.80mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description Tape & Reel (TR) 7WT74 TC7WT Non-Inverting flip flop 0.635mm 30ns @ 5.5V 50pF 53MHz 30ns
PDF
/
Inventory: 1143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.110, 2.80mm Width)
Number of Pins 8

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2010
Series TC7WT
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type D-Type
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.635mm
Base Part Number 7WT74
Function Set(Preset) and Reset
Qualification Status Not Qualified
Output Type Differential
Operating Supply Voltage 5V
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 1
Load Capacitance 50pF
Clock Frequency 53MHz
Propagation Delay 30 ns
Quiescent Current 2μA
Turn On Delay Time 17 ns
Logic Function AND, D-Type
Current - Output High, Low 4mA 4mA
Max I(ol) 0.004 A
Max Propagation Delay @ V, Max CL 30ns @ 5.5V, 50pF
Trigger Type Positive Edge
Input Capacitance 5pF
Clock Edge Trigger Type Positive Edge

Compliance

RoHS Status RoHS Compliant
