SN74LVC1G74DCTR
RoHS
RoHS compliant
RoHS compliantPackage 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74LVC1G74 e4 74LVC flip flop 2.95mm 6.4ns @ 5V 50pF 200MHz 7.9ns
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.44968
≥100 USD $0.4224
≥500 USD $0.344872
≥1000 USD $0.320285
≥3000 USD $0.272589
Inventory: 30948
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type D-Type
Subcategory FF/Latches
Packing Method TR
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number 74LVC1G74
Function Set(Preset) and Reset
Output Type Differential
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3V
Number of Circuits 1
Nominal Supply Current 10μA
Output Current 50mA
Number of Bits 1
Clock Frequency 200MHz
Propagation Delay 6.4 ns
Quiescent Current 10μA
Turn On Delay Time 1.6 ns
Family LVC/LCX/Z
Logic Function AND, D-Type, Flip-Flop
Current - Output High, Low 32mA 32mA
Number of Gates 2
Max Propagation Delay @ V, Max CL 6.4ns @ 5V, 50pF
Prop. Delay@Nom-Sup 7.9 ns
Trigger Type Positive Edge
Input Capacitance 5pF
Clock Edge Trigger Type Positive Edge
Ambient Temperature Range High 125°C
Dimensions
Height 1.3mm
Length 2.95mm
Width 2.8mm
Thickness 1.29mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
