SN74LVC1G175DCKR
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Cut Tape (CT) 74LVC1G175 e4 74LVC flip flop 2mm 5ns @ 5V 50pF 175MHz 13.4ns
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.27896
≥100 USD $0.233728
≥500 USD $0.148016
≥1000 USD $0.114259
≥3000 USD $0.097398
Inventory: 28387
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Number of Pins 6
Weight 2.494758mg
Manufacturer Package Identifier DCk(R-PDSO-G6)
Technical
Operating Temperature -40°C~125°C TA
Packaging Cut Tape (CT)
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type D-Type
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory FF/Latches
Packing Method TR
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Base Part Number 74LVC1G175
Function Reset
Output Type Non-Inverted
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3V
Number of Circuits 1
Load Capacitance 50pF
Output Current 32mA
Number of Bits 1
Clock Frequency 175MHz
Propagation Delay 13.4 ns
Turn On Delay Time 1 ns
Family LVC/LCX/Z
Current - Quiescent (Iq) 10μA
Output Characteristics 3-STATE
Current - Output High, Low 32mA 32mA
Max I(ol) 0.032 A
Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
Trigger Type Positive Edge
Input Capacitance 3pF
Clock Edge Trigger Type Positive Edge
Dimensions
Height 1.1mm
Length 2mm
Width 1.25mm
Thickness 900μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
