SN74LS76AD
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
COMPLEMENTARY Contains Lead Not Qualified Set(Preset) and Reset flip flop 0C~70C TA 400muA 8mA 4.75V~5.25V 20ns
PDF
/
Inventory: 1313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Output Type Differential
Number of Elements 2
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Clock Frequency 45MHz
Propagation Delay 20 ns
Quiescent Current 4mA
Family LS
Logic Function AND
Current - Output High, Low 400μA 8mA
Output Polarity COMPLEMENTARY
Number of Bits per Element 1
Max Propagation Delay @ V, Max CL 20ns @ 5V, 15pF
Trigger Type Negative Edge
Power Supply Current-Max (ICC) 6mA
fmax-Min 45 MHz
Clock Edge Trigger Type Positive Edge
Qualification Status Not Qualified
Function Set(Preset) and Reset
Base Part Number 74LS76
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Subcategory FF/Latches
Additional Feature MASTER SLAVE OPERATION
Type JK Type
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C TA
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
