SN74LS74AN
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74LS74 74LS Non-Inverting flip flop 19.3mm 25ns @ 2.5V 15pF 33MHz 40ns
PDF
/
Buying Options
Total Price: USD $2.2
Unit Price: USD $2.2
≥1 USD $2.2
Inventory: 197
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Clock Edge Trigger Type Positive Edge
Number of Output Lines 1
Number of Input Lines 3
Low Level Output Current 8mA
High Level Output Current -400μA
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 25ns @ 2.5V, 15pF
Max Frequency 33MHz
Number of Bits per Element 1
Current - Output High, Low 400μA 8mA
Current - Quiescent (Iq) 8mA
Logic Function AND, D-Type, Flip-Flop, Latch
Turn On Delay Time 13 ns
Propagation Delay 40 ns
Clock Frequency 33MHz
Number of Bits 2
Output Current 8mA
Nominal Supply Current 25mA
Operating Supply Current 25mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Number of Circuits 2
Number of Channels 2
Polarity Non-Inverting
Number of Elements 2
Operating Supply Voltage 5V
Output Type Differential
Function Set(Preset) and Reset
Base Part Number 74LS74
Frequency 33MHz
Voltage - Supply 4.75V~5.25V
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Type D-Type
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 927.99329mg
Supplier Device Package 14-PDIP
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 17 hours ago)
Factory Lead Time 12 Weeks
