SN74HCT574PWT
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Standard D-Type Flip Flop -40C~85C TA 8muA 3pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.1176
≥1 USD $1.1176
Inventory: 69
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
Technical
Max Frequency@Nom-Sup 27000000Hz
Clock Edge Trigger Type Positive Edge
Count Direction UNIDIRECTIONAL
Number of Input Lines 3
Input Capacitance 3pF
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 45 ns
Max Propagation Delay @ V, Max CL 47ns @ 5.5V, 150pF
Max I(ol) 0.006 A
Current - Output High, Low 6mA 6mA
Current - Quiescent (Iq) 8μA
Logic Function D-Type, Flip-Flop
Family HCT
Turn On Delay Time 25 ns
Propagation Delay 53 ns
Clock Frequency 40MHz
Number of Bits 8
Output Current 6mA
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Standard
Base Part Number 74HCT574
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 76.997305mg
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
